Key Features & Benefits
| Feature | Benefit to You |
|---|---|
| Weichai WP12 Series Engine – 460 HP | Industry-proven powerplant delivers high torque for steep grades and rough terrain; fuel-efficient design reduces operating costs |
| FAST 7DS Series Transmission | Robust gearbox with 7 forward gears and twin-countershaft design; handles high torque loads with exceptional reliability |
| 60-Ton Rated Payload | Move more material per trip-fewer cycles, less fuel burn, higher daily production |
| 31.5–37 m³ Heaped Capacity | Large-capacity body reduces the number of loads needed; choose the right volume for your material density |
| Slide-Type Front Suspension + Maintenance-Free Balanced Shaft | Industry-first design improves ride comfort and stability; reduces maintenance time and parts replacement frequency |
| Heavy-Duty Axles (20T + 35T + 35T) | Triple-axle configuration with optimized load distribution; built to withstand constant heavy hauling |
| 14.00R25 Heavy-Duty Tires | Rugged tires provide excellent traction on loose or uneven surfaces; reduced tire wear in abrasive conditions |
| Flip-Over Wide Cab | Spacious, well-insulated cab reduces driver fatigue; easy tilting for maintenance access to drivetrain components |
Built for the Toughest Applications
The MT86H is a proven performer across a wide range of mining and earthmoving operations :
Open-Pit Coal Mines – Hauling overburden and coal with high efficiency
Limestone & Aggregate Quarries – Moving heavy rock in high-abrasion environments
Non-Ferrous Metals Mines – Copper, iron ore, and other hard rock applications
Large-Scale Construction Sites – Earthmoving and material transport for major infrastructure
Stone and Gravel Operations – Where payload and reliability are non-negotiable
►
Engineered for Operator Comfort and Safety
A productive haul truck is one that operators can run shift after shift without excessive fatigue. The MT86H's cab is designed with the operator in mind :
Spacious, flip-over cab – Provides excellent visibility and easy ingress/egress
Noise and heat insulation – Reduced cabin noise and temperature for year-round comfort
Advanced suspension system – Slide-type front suspension absorbs shocks from rough haul roads
Secondary cushioning – Additional shock absorption reduces driver fatigue on long hauls
Maintenance Made Simple
Mining equipment must be easy to service-and the MT86H delivers :
Modular design – Key components are easy to access for inspection and replacement
Tilt-up cab – Quick access to the engine and transmission for service tasks
Maintenance-free suspension components – Reduced daily greasing and parts replacement
Industry-standard components – Widely available parts ensure fast repairs and minimal downtime
product detail drawing
Products Description
Product Specifications
| Parameter | Specification |
|---|---|
| Model | MT86H |
🔹 Weight & Dimensions
| Parameter | Specification |
|---|---|
| Rated Payload | 60,000 kg |
| Curb Weight | 31,700 kg |
| Gross Vehicle Weight | 91,700 kg |
| Overall Dimensions (L×W×H) | 8,840 × 3,550 × 4,050 mm |
🔹 Engine
| Parameter | Specification |
|---|---|
| Model | WEICHAI WP12G460E310 |
| Power | 460 hp |
🔹 Transmission
| Parameter | Specification |
|---|---|
| Model | FAST 7DS200 / FC6A210 |
🔹 Axle
| Parameter | Specification |
|---|---|
| Front & Rear Axle Ratings | 20 + 35 + 35 (tons) |
🔹 Tires
| Parameter | Specification |
|---|---|
| Type | 14.00-25 / 14.00R25 |
🔹 Standard Body Capacity
| Parameter | Specification |
|---|---|
| Struck / Heaped | 29.5 – 34 / 36 – 40 (m³) |
Note: Corrected unit from "m²" to "m³" (cubic meters) as standard for dump truck body volume.
🔹 Performance Parameters
| Parameter | Specification |
|---|---|
| Max. Speed – Unladen / Laden | 45 / 45 (km/h) |
| Max. Gradeability | 30% |
| Min. Turning Diameter | 22 (m) |
| Min. Ground Clearance | 310 (mm) |
🔹 Quick Reference Summary
| Category | Detail |
|---|---|
| Model | MT86H |
| Payload | 60 tons |
| Engine | WEICHAI WP12G460E310 – 460 hp |
| Transmission | FAST 7DS200 / FC6A210 |
| Axle Configuration | 20T + 35T + 35T |
| Tires | 14.00-25 / 14.00R25 |
| Body Capacity (Heaped) | 36 – 40 m³ |
| Top Speed | 45 km/h |
| Max. Gradeability | 30% |
| Turning Diameter | 22 m |
| Ground Clearance | 310 mm |
Products Description
why choose us
'lt is awesome to work with Creative. amazingy organized,easy to communicate with. responsive with next iterations,and beautiful work.
Quality Assurance:
Key components (engine, transmission) of the entire vehicle are guaranteed for replacement within one year upon delivery.
Export Experience:
With 7 years of experience in exporting complete vehicles and accessories, we have exported to over 30 countries.
After-sales Service:
Technical support, remote video support, local driver training services, providing vehicle consumable parts sales services for up to 10 years, ensuring you don't have to worry about not being able to obtain original vehicle parts.
Customization Capability:
We can customize according to your specific project requirements.
Customer feedback and delivery details
FAQ
Q: Who are we?
A: YALONG'S headquarters is located in Shandong, China. Since 2018, we have been selling to Africa (30.00%), South Asia (20.00%), Southeast Asia (20.00%), Middle East (20.00%), and domestic market (10.00%). There are about 11-50 people in our office.
Q: why should you buy from us not from other suppliers?
A: We adhere to the business philosophy of "quality first, customer first" and have won the trust and support of domestic and foreign customers with excellent product quality, good service attitude, and reasonable sales prices. The main export countries and regions are: Africa, Southeast Asia, Central Asia, South America and other places. We have a professional design and development team that can design and develop a car that is more suitable for you according to your needs; rich export experience, familiar with the export procedures and required certifications of various countries, and can deliver your car to you faster; We With first-class production equipment, strong technical force and advanced testing methods, we can provide you with more stable and reliable vehicles.
Q: How can we guarantee quality?
A: Always a pre-production sample before mass production; Always final Inspection before shipment;
Q: Why should you buy from us not from other suppliers?
A: YALONG is a company specializing in the export of used commercial vehicles, providing one-stop services such as procurement, preparation, inspection, customs declaration, transportation, and customs clearance at the destination for foreign customs.
Q: How is your after-sales service technical team?
A: Not only are we a trading company, but we have a team of engineers and professional maintenance staff who have been working in the field of construction machinery for nearly 20 years. We can provide you with online service support in a timely manner, or send it to the China Manufacturing network for support when needed. Hot Tags: howo 6x4 dump truck for mining, China howo 6x4 dump truck for mining manufacturers, suppliers Hot Tags: 6x4 howo mining dump truck, China 6x4 howo mining dump truck manufacturers, suppliers, heavy head truck, heavy truck tractor, Howo 10 Wheel Tipper Truck, HOWO Durable Construction Dump Truck, howo truck dump, loading tractor truck
